These 8-bit addressable latches are designed for general purpose storage applications in digital systems. Specific uses include working registers, serial-holding registers, and active-high decoders or demultiplexers. They are multifunctional devices capable of storing single line data in eight addressable latches, and being a 1-of-8 decoder or demultiplexer with active high outputs

The 74HC540 is identical in pinout to the LS540. The device inputs are compatible with Standard CMOS outputs. External pull?up resistors make them compatible with LSTTL outputs. The HC540A is an octal inverting buffer/line driver/line receiver designed to be used with 3?state memory address drivers, clock drivers, and other bus?oriented systems. This device features inputs and outputs on opposite sides of the package and two ANDed active?low output enables.

74HC540 is a 20 Pin Octal 3-state Inverting Buffer IC having 2V to 6V Operating Voltage range with 6mA output current. The 3-STATE  buffers  utilize  advanced  silicon-gate  CMOS  technology.  They  possess  high  drive  current  outputs  which enable  high  speed operation  even  when  driving  large  bus  capacitances. These  circuits  achieve  speeds  comparable  to  low  power Schottky devices, while retaining the advantage of CMOS circuitry, i.e., high noise immunity, and low power consumption. Both devices have a fanout of 15 LS-TTL equivalent inputs. The  74HC540  is  an  inverting  buffer  and  the MM74HC541 is a non-inverting buffer. The 3-STATE control gate operates as a two-input NOR such that if either G1 or  G2  are  HIGH,  all  eight  outputs  are  in  the  high-impedance state.

The 74HC573 devices are octal transparent D-type latches that feature 3-state outputs designed specifically for driving highly capacitive or relatively low-impedance loads. They are particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers. While the latch-enable (LE) input is high, the Q outputs respond to the data (D) inputs. When LE is low, the outputs are latched to retain the data that was set up.

The 74HC573 high speed octal D-type latches utilize advanced silicon-gate P-well CMOS technology. They possess the high noise immunity and low power consumption of standard CMOS integrated circuits, as well as the ability to drive 15 LS-TTL loads. Due to the large output drive capability and the 3-STATE feature, these devices are ideally suited for interfacing with bus lines in a bus organized system.

The 74HC574 high speed octal D?type flip?flops utilize advanced silicon?gate P?well CMOS technology. They possess the high noise immunity and low power consumption of standard CMOS integrated circuits, as well as the ability to drive 15 LS?TTL loads. Due to the large output drive capability and the 3?STATE feature, these devices are ideally suited for interfacing with bus lines in a bus organized system. These devices are positive edge triggered flip?flops. Data at the D inputs, meeting the set?up and hold time requirements, are transferred to the Q outputs on positive going transitions of the CLOCK (CK) input. When a high logic level is applied to the OUTPUT CONTROL (OC) input, all outputs go to a high impedance state, regardless of what signals are present at the other inputs and the state of the storage elements. The 74HC logic family is speed, function, and pinout compatible with the standard 74LS logic family. All inputs are protected from damage due to static discharge by internal diode clamps to VCC and ground.

The 74HC574 high speed octal D-type flip-flops utilize advanced silicon-gate P-well CMOS technology. They possess the high noise immunity and low power consumption of standard CMOS integrated circuits, as well as the ability to drive 15 LS-TTL loads. Due to the large output drive capability and the 3-STATE feature, these devices are ideally suited for interfacing with bus lines in a bus organized system. These devices are positive edge triggered flip-flops.
